Hoist Oxford Calibre
Brand: Joerns - View all products
The Oxford Calibre Hoist is a robust, ergonomically designed professional patient lift built specifically for bariatric care. With an impressive safe working load of 385 kg, it provides safe and efficient transfers for larger individuals while ensuring comfort and security throughout the process.
Purpose-built for bariatric environments, the Calibre works seamlessly with its dedicated sling range to meet the unique demands of bariatric patients. Its sturdy construction, integrated weigh-scale, and advanced safety features make it a dependable solution for hospitals and care facilities.
Key Features
- Safe working load: 385 kg (60 st / 850 lbs)
- Integrated Class III digital weigh-scale for accurate patient monitoring
- Large 6-point cradle enhances comfort for bariatric clients
- Powered leg positioning system provides excellent access around furniture
- Ergonomic design with oversized push handle for multi-person operation
- Twin pivoted front castors for smooth manoeuvrability
- Smart Monitor with diagnostic and service controls as standard
- Integrated safety systems protect both patient and caregiver
Size Chart
| Size | CM |
| Safe Working Load | 385 kg |
| Maximum Overall Length | 180.5 |
| Minimum Overall Length | 174 |
| Maximum Overall Height | 221 |
| Minimum Overall Height | 157.5 |
| Maximum Height to Attachment Point | 185.5 |
| Minimum Height to Attachment Point | 65 |
| Height at Maximum Reach | 173 |
| Reach at Maximum Height | 57 |
| Reach at Minimum Height | 72.5 |
| Maximum Reach | 82.5 |
| Turning Radius | 196 |
| Legs Open – External Width | 142 |
| Legs Open – Internal Width | 124.5 |
| Legs Closed – External Width | 88.5 |
| Legs Closed – Internal Width | 70 |
| Overall Height of Legs | 13 |
| Ground Clearance | 2 |
| Front Twin Castors | 10 |
| Rear Braked Castors | 10 |
| Mast, Base & Boom Assembly (including 6-point cradle) | 109 kg |
| Power Pack | 3 kg |
| Total | 112 kg |
| 6-point Cradle | 9 kg |
€17,422.83
Inc VAT
