Hoist Oxford Presence
Brand: Joerns - View all products
The Oxford Presence Hoist is a heavy-duty professional patient lift designed to manage a wide variety of lifting and transfer needs. Built for durability and performance, it combines strength with versatility, making it suitable for both critical and everyday transfers in care environments.
With an outstanding lifting range from 44 cm to 191 cm, the Presence ensures smooth transfers to and from the floor, bed, or higher surfaces. Its ergonomic design, powered features, and advanced safety systems provide reassurance for both patients and carers during use.
Key Features
- Safe working load: 227 kg (35 st / 500 lbs)
- Exceptional lifting range from 440 mm to 1910 mm
- Smart Monitor with diagnostic and service controls as standard
- Interchangeable spreader bar and cradle options for flexibility
- Powered leg positioning system ensures easy access around furniture
- Low leg model available for use with low bed frames
- Powered cradle and digital weigh-scale options for enhanced care
- Ergonomic design with intuitive interaction points for carers
- Integrated safety systems provide protection for patients and carers
Size Chart
| Size | CM |
| Safe Working Load | 227 kgs |
| Maximum Overall Length | 146 |
| Minimum Overall Length | 140 |
| Maximum Overall Height | 206.5 |
| Minimum Overall Height | 146 |
| Spreader Bar – Maximum Height | 191 |
| Spreader Bar – Minimum Height | 43 |
| Height at Maximum Reach | 131 |
| Reach at Maximum Height | 65 |
| Reach at Minimum Height | 40 |
| Maximum Reach (Centre of spreader bar to front of the mast) | 93 |
| Turning Radius | 163 |
| Legs Open – External Width | 115 |
| Legs Open – Internal Width | 102 |
| Legs Closed – External Width | 67 |
| Legs Closed – Internal Width | 55 |
| Overall Height of Legs | 12 |
| Overall Height of Legs (Low leg model) | 5.9 |
| Ground Clearance | 3.5 |
| Ground Clearance (Low leg model) | 2 |
| Front Twin Castors | 10 |
| Front Twin Castors (Low leg model) | 5 |
| Rear Braked Castors | 10 |
| 4-point Positioning Cradle – Maximum Height | 155 |
| 4-point Positioning Cradle – Minimum Height (usable) | 39 |
| Mast, Base & Boom Assembly (includes 6-point spreader bar) | 37.0 kg |
| Power Pack | 3.0 kg |
| Total (including 6-point spreader bar) | 40.0 kg |
| Base Assembly | 20.0 kg |
| Mast & Boom Assembly (excluding battery) | 17.0 kg |
| 4-point Positioning Cradle (manual operation) | 6.0 kg |
| 4-point Positioning Cradle (powered operation) | 9.0 kg |
